Univariate multi-step timeseries forecasting with Keras
A example of using an LSTM network to forecast an univariate multi-step timeseries with Keras.
Import the must-have
libraries:
import numpy as np
import pandas as pd
import datetime as dt
from IPython import display as ids
Import the elements required from the scikit-learn
library:
import sklearn as sk
import sklearn.preprocessing as skp
import sklearn.model_selection as skms
import sklearn.pipeline as skpl
import sklearn.decomposition as skd
import sklearn.linear_model as sklm
import sklearn.dummy as sky
import sklearn.metrics as skme
Enables defining partial functions:
from functools import partial
Import the keras
elements from the tensorflow
library:
import tensorflow as tf
from tensorflow import keras as k
from tensorflow.keras import backend as kb
from tensorflow.keras import callbacks as kc
from tensorflow.keras import models as km
from tensorflow.keras import layers as kl
from tensorflow.keras import regularizers as kr
from tensorflow.keras import optimizers as ko
from tensorflow.keras import utils as ku
Import matplotlib
and set the default magic:
import matplotlib as mat
from matplotlib import pyplot as plt
import pylab as pyl
import seaborn as sns
%matplotlib inline
%config InlineBackend.figure_format = 'retina'
Import the mlviz
library used to plot time-series
visualizations:
from mlviz.timeseries import visualizationhelpers as mwvh
from mlviz.utilities import graphichelpers as mwgh
Reset the predefined matplotlib
style:
mwgh.GraphicsStatics.initialize_matplotlib_styles()
Here is the color palette we'll use for the project:
sns.palplot(mwgh.GraphicsStatics.g_palette)
Let's capture all the usefull project's parameters in a dictionary:
params = {}
params['project_date'] = '2021-05-31'
params['project_name'] = 'LSTM+01'
params['experiment_timestamp'] = str(int(1000 * dt.datetime.timestamp(dt.datetime.utcnow())))
params['experiment_name'] = '{0}-{1}-{2}'.format(
params['project_date'],
params['experiment_timestamp'],
params['project_name'])
params['data_frequency'] = 'W-SAT'
params['features'] = ['y']
params['input_size'] = 52 # N weeks of data to input into the network
params['output_size'] = 13 # N weeks of data to output from the network
params['testing_size'] = 52 # N weeks of data to keep for testing the model
params['lag_size'] = None
params['hyperband_iterations'] = 3
params['max_epochs'] = 250
params['patience'] = int(params['max_epochs'] / 10)
params['batch_size'] = 16
The input data is available in a csv
file named timeseries-data.csv
located in the data
folder. It has got 2 columns date
containing the date of event and value
holding the value of the source. We'll rename these 2 columns as ds
and y
for convenience. Let's load the csv
file using the pandas
library and have a look at the data.
df = pd.read_csv(
filepath_or_buffer='../assets/data/timeseries-data.csv',
sep=';')
df.rename(
columns = {
'date': 'index',
'value': 'y'
},
inplace=True)
df['index'] = pd.to_datetime(
arg=df['index'],
dayfirst=True)
df.sort_values(
by='index',
ascending=True,
inplace=True)
df.set_index(
keys='index',
inplace=True)
df = df.asfreq(
freq=params['data_frequency'])
df['ds'] = df.index
print('df.shape = {0}'.format(df.shape))
df.tail(5)
It's easy to calculate the width of a sample:
def get_maximum_lag_size(lag_data):
steps_lag = 0
if lag_data is not None and len(lag_data) > 0:
steps_lag = max(lag_data)
return steps_lag
sample_width = get_maximum_lag_size(params['lag_size']) + params['input_size'] + params['output_size']
print('sample_width: {0}'.format(sample_width))
To avoid any overlap between the training
and the testing
data set, we'll first split the dataframes, keeping params['testing_size']
samples for testing our model. We need to make sure that no data point used for training is also used for testing our model.
threshold_date = pd.to_datetime(df.index[df.shape[0] - (sample_width + params['testing_size'])])
print('Cutoff date for training/testing split is {0}'.format(threshold_date.strftime('%d/%m/%Y')))
Let's cut the dataframe at the right date:
test_mask = (df['ds'] > threshold_date)
df_train = df[~test_mask]
df_test = df[test_mask]
print('df_train.shape = {0}'.format(df_train.shape))
print('df_test.shape = {0}'.format(df_test.shape))
The prepare_data
funtion will take care of doing exactly this:
def prepare_data(data, lag_data, cols_in, steps_in, cols_out, steps_out, scaler_in=None, scaler_out=None):
df = data.copy()
cols_in_original = [col for col in cols_in]
cols_in_processed = [col for col in cols_in]
steps_lag = get_maximum_lag_size(lag_data)
if steps_lag > 0:
for col in cols_in_original:
for i, lag in enumerate(lag_data):
lag_col = '{0}_{1}'.format(col, lag)
df[lag_col] = df[col].shift(lag)
cols_in_processed.append(lag_col)
samples = df.shape[0] - (steps_in + steps_out + steps_lag) + 1
if samples < 1:
raise ValueError('not enough data to produce 1 sample.')
index = list(df.index)
cols_in_indices = {name: i for i, name in enumerate(cols_in_processed)}
cols_out_indices = {name: i for i, name in enumerate(cols_out)}
df.reset_index(inplace=True)
X_input_scaled = None
if scaler_in is None:
scaler_in = skpl.Pipeline([
('std', skp.StandardScaler()),
('minmax', skp.MinMaxScaler(feature_range=(-1, 1)))])
X_input_scaled = scaler_in.fit_transform(df[cols_in_processed].values)
else:
X_input_scaled = scaler_in.transform(df[cols_in_processed].values)
y_output_scaled = None
if scaler_out is None:
scaler_out = skpl.Pipeline([
('std', skp.StandardScaler()),
('minmax', skp.MinMaxScaler(feature_range=(-1, 1)))])
y_output_scaled = scaler_out.fit_transform(df[cols_out].values)
else:
y_output_scaled = scaler_out.transform(df[cols_out].values)
X = []
y = []
for sample in range(samples):
for step_in in range(steps_in):
for col_in in range(len(cols_in_processed)):
X.append(X_input_scaled[sample+steps_lag+step_in, col_in])
for step_out in range(steps_out):
for col_out in range(len(cols_out)):
y.append(y_output_scaled[sample+steps_lag+steps_in+step_out, col_out])
X = np.array(X).reshape(samples, steps_in, len(cols_in_processed))
y = np.array(y).reshape(samples, steps_out, len(cols_out))
return X, y, index, scaler_in, scaler_out, cols_in_indices, cols_out_indices
Every intput feature (passed via the function parameter cols_in
) is going to be rescalled using a scikit-learn
pipeline containing first a StandardScaler
and then a MinMaxScaler
in order to end up with a feature range of [-1, +1]
required by neural networks.
X_train, y_train, index_train, scaler_in, scaler_out, cols_in_indices_train, cols_out_indices_train = prepare_data(
data=df_train,
lag_data=params['lag_size'],
cols_in=params['features'],
steps_in=params['input_size'],
cols_out=params['features'],
steps_out=params['output_size'])
print('X_train.shape: {0}'.format(X_train.shape))
print('y_train.shape: {0}'.format(y_train.shape))
To prepare the testing
data, we need to reuse both input (variable scaler_in
) and output (variable scaler_out
) pipelines in order to keep data scaled in the same way.
X_test, y_test, index_test, _, _, cols_in_indices_test, cols_out_indices_test = prepare_data(
data=df_test,
lag_data=params['lag_size'],
cols_in=params['features'],
steps_in=params['input_size'],
cols_out=params['features'],
steps_out=params['output_size'],
scaler_in=scaler_in,
scaler_out=scaler_out)
print('X_test.shape: {0}'.format(X_test.shape))
print('y_test.shape: {0}'.format(y_test.shape))
Let's compute the entire dataset and keep the output data for visualization:
X, y, index, _, _, cols_in_indices, cols_out_indices = prepare_data(
data=df,
lag_data=params['lag_size'],
cols_in=params['features'],
steps_in=params['input_size'],
cols_out=params['features'],
steps_out=params['output_size'],
scaler_in=scaler_in,
scaler_out=scaler_out)
print('X.shape: {0}'.format(X.shape))
print('y.shape: {0}'.format(y.shape))
Let's have a look at the visual representation of the timeseries data:
mwvh.plot_time_series(
title='timeseries visualization',
subtitle='data preparation',
name=('Input - Data Visualization{0}' +
'Training - {1} weeks ({2} samples){0}' +
'Testing - {3} weeks ({4} samples)').format(
'\n',
df_train.shape[0],
X_train.shape[0],
df_test.shape[0],
X_test.shape[0]),
training=df_train,
testing=df_test,
ylabel='feature value (y)',
split=threshold_date)
We'll use RMSE
as our loss function to optimize (it is required to be defined as a function that can be compiled by TensorFlow
):
def rmse_tf(y_true, y_pred):
return tf.cast(
tf.sqrt(
tf.reduce_mean(
tf.square(
tf.subtract(
y_pred,
y_true)))),
dtype=tf.float32)
First, we define a create_model
function:
def create_model(loss_fn, steps_in, steps_out, n_features):
# define model
model = km.Sequential()
model.add(kl.LSTM(steps_in, activation='tanh', return_sequences=True, input_shape=(steps_in, n_features)))
model.add(kl.LSTM(2*steps_in, activation='tanh', return_sequences=True, dropout=.5))
model.add(kl.LSTM(4*steps_in, activation='tanh'))
model.add(kl.Dense(steps_out, activation='tanh'))
model.compile(optimizer='adam', loss=loss_fn)
return model
model = create_model(
loss_fn=rmse_tf,
steps_in=params['input_size'],
steps_out=params['output_size'],
n_features=len(params['features']))
Let's fit this model using the data we loaded earlier:
print('X_train.shape: {0}'.format(X_train.shape))
print('y_train.shape: {0}'.format(y_train.shape))
history = model.fit(
x=X_train,
y=y_train,
shuffle=True,
batch_size=params['batch_size'],
validation_data=(X_test, y_test),
epochs=params['max_epochs'],
callbacks=[
kc.EarlyStopping(
monitor='val_loss',
patience=params['patience'],
verbose=1,
mode='min',
restore_best_weights=True),
kc.TerminateOnNaN()
],
verbose=2)
Here is a text version of the model's architecture made with Keras itself.
model.summary(
line_length=120)
We can save this default model and use the Netron application to create a visual representation of it.
model.save(
'./.models/{0}.h5'.format(
params['experiment_name']))
We can see the optimization process on the chart below.
def plot_model_history(history):
'''
Summarizes the history for all loss functions,
throughout the epochs.
'''
for fn in list(history.history.keys()):
plt.plot(history.history[fn])
plt.title('Model loss')
plt.ylabel('loss')
plt.xlabel('epoch')
plt.legend(list(history.history.keys()), loc='upper right')
plt.show()
plot_model_history(history=history)
Let's zoom in and focus on the last n weeks of data.
def get_n_weeks_window(n_weeks):
return dt.timedelta(weeks=n_weeks)
We need a functions to compute the various model scores.
def score(loss_fn, y_true, y_pred):
if loss_fn == 'RMSE':
return skme.mean_squared_error(
y_true=y_true,
y_pred=y_pred,
squared=False)
elif loss_fn == 'MSLE':
return skme.mean_squared_log_error(
y_true=y_true,
y_pred=y_pred)
elif loss_fn == 'MSE':
return skme.mean_squared_error(
y_true=y_true,
y_pred=y_pred,
squared=True)
elif loss_fn == 'R2':
return skme.r2_score(
y_true=y_true,
y_pred=y_pred)
elif loss_fn == 'MAE':
return skme.mean_absolute_error(
y_true=y_true,
y_pred=y_pred)
elif loss_fn == 'MAPE':
return skme.mean_absolute_percentage_error(
y_true=y_true,
y_pred=y_pred)
We can process de predicted values returned by the model. The model sequencialy produces params['output_size']
data points (i.e. the number of weeks of data points predicted). Predictions will enventually overlap, so we can use the mean
function to get a good candidate of the current value. Similarly, the min
and the max
will provide a convenient confidence interval.
def process_predictions(data, X, y, scaler_out, model):
data_pre = data.copy()
scores = []
predictions = []
score_functions = ['RMSE', 'MSE', 'R2', 'MAE', 'MAPE']
lag_data = params['lag_size']
steps_lag = 0
if lag_data is not None and len(lag_data) > 0:
steps_lag = max(lag_data)
y_preds = model.predict(
x=X,
batch_size=params['batch_size'],
verbose=0)
# print('y_preds.shape: {0}'.format(y_preds.shape))
y_true_array = []
y_pred_array = []
for i in range(y.shape[0]):
t_score = {}
y_true = scaler_out.inverse_transform(y[i])
y_pred = scaler_out.inverse_transform(y_preds[i].reshape(-1, 1))
y_true_array.append(y_true)
y_pred_array.append(y_pred)
for score_function in score_functions:
t_score[score_function] = score(
score_function,
y_true,
y_pred)
scores.append(t_score)
prediction = [np.nan] * data_pre.shape[0]
for j in range(len(y_true)):
position = steps_lag + i + j + params['input_size']
prediction[position] = y_pred[j][0]
predictions.append(
prediction)
df_scores = pd.DataFrame.from_records(scores)
data_pre['yhat_lower'] = pd.DataFrame(predictions).min().values
data_pre['yhat_upper'] = pd.DataFrame(predictions).max().values
data_pre['yhat'] = pd.DataFrame(predictions).mean().values
data_pre['yhat_last'] = predictions[-1]
data_pre['residual'] = abs(data_pre['yhat'] - data_pre['y'])
pred = {
'df': data_pre,
'scores': df_scores,
'y_true': y_true_array,
'y_pred': y_pred_array,
'predictions': predictions
}
return pred
pred = process_predictions(
data=df,
X=X,
y=y,
scaler_out=scaler_out,
model=model)
Let's have a look at the model performance:
upper_percentile_score = pred['scores'].iloc[-X_test.shape[0]:]['RMSE'].describe()['75%']
print('75 percentile score: {0:.2f}'.format(upper_percentile_score))
We can see on the chart that the predictions are quite basic but still properly following the local trend as well as the seasonal variations.
mwvh.plot_time_series(
title='Time Series Visualization',
subtitle='default model predictions',
name=('Input - Data Visualization{0}' +
'Training - {1} weeks ({2} samples){0}' +
'Testing - {3} weeks ({4} samples)').format(
'\n',
df_train.shape[0],
X_train.shape[0],
df_test.shape[0],
X_test.shape[0]),
training=df_train,
testing=df_test,
confidence=pred['df'],
confidence_label='Confidence interval',
prediction=pred['df'],
residual=pred['df'],
residual_label='Residual error',
ylabel='feature value (y)',
split=threshold_date,
window_size=get_n_weeks_window(16*params['output_size']))
mwvh.plot_time_series(
title='Time Series Visualization',
subtitle='default model predictions',
name=('Input - Data Visualization{0}' +
'Training - {1} weeks ({2} samples){0}' +
'Testing - {3} weeks ({4} samples)').format(
'\n',
df_train.shape[0],
X_train.shape[0],
df_test.shape[0],
X_test.shape[0]),
testing=df_test,
confidence=pred['df'],
confidence_label='Confidence interval',
prediction=pred['df'],
prediction_col='yhat',
residual=pred['df'],
residual_label='Residual error',
ylabel='feature value (y)',
window_size=get_n_weeks_window(4*params['output_size']))
